Doosan Lynx 220 LY C
Cnc Lathe
 |
|
Equipment and Features
Used Doosan 220LY CNC Turning Centre in Excellent Condition
A high-speed, multi-axis CNC lathe built for precision, efficiency, and flexibility. The Doosan 220LY features live tooling, Y-axis capability, and a 12-station turret – making it ideal for complex turning and milling applications in a compact footprint. Available for a powered Demo
Machine Specification
CAPACITY
Swing Over Bed: 600 mm
Swing Over Saddle: 400 mm
Max Turning Diameter: 300 mm
Recommended Turning Diameter: 210 mm
Max Turning Length: 130 mm
Max Bar Capacity: 65 mm
SPINDLE
Max Spindle Speed: 6,000 rpm
Spindle Nose: A2-6
Spindle Through-Hole Diameter: 76 mm
Spindle Bearing Diameter (Front): 110 mm
C-Axis Indexing: 360°
Spindle Motor Power: 15 / 11 kW
TURRET
Tool Type: BMT Block
Tool Capacity: 12 Stations
OD Tool Size: 20 x 20 mm
Boring Bar Diameter: 32 / 20 mm
Rotary Tool Speed: 6,000 rpm
Rotary Tool Motor Power: 3.7 kW
FEEDRATES & TRAVELS
X Axis Travel: 205 mm
Z Axis Travel: 560 mm
Y Axis Travel: 105 mm (±52.5 mm)
Rapid Traverse (X Axis): 30 m/min
Rapid Traverse (Z Axis): 36 m/min
Rapid Traverse (Y Axis): 10 m/min
TAILSTOCK
Quill Diameter: 65 mm
Quill Bore Taper: MT#4
Quill Travel: 80 mm
MOTORS & POWER
Feed Motors (X / Y / Z): 1.8 / 2.5 / 1.8 kW
Coolant Pump Motor: 1.5 kW
Power Supply (Rated Capacity): 28.22 kVA
POA
